24V 100Ah
零售价
0.0
元
市场价
0.0
元
浏览量:
1000
产品编号
数量
-
+
库存:
0
所属分类
返回列表
1
产品描述
参数
| Main Specification | |||
| Power Supply (Pure Sine wave Inverter) | |||
| Model NO.: | PS-U24220-1500W | ||
| Input Rated Voltage | 24 Vdc (21～30±0.5Vdc) | ||
| Input Rated Current | 100A Max(@.24Vdc,Full Load) | ||
| Efficiency | 92% (@ 24Vdc,Full Load 1500W) | ||
| Output Rated Voltage(AC) | 220 Vac(198~242 Vac) | ||
| Output Rated Frequency(AC) | 50Hz | ||
| Output Rated Power(AC) | 1500W(@25°C) | ||
| Output Peak power(AC) | 3000W(@26°C) | ||
| Turn ON Delay Time | 1000mS Max @24VDC input and full output load | ||
| Short Circuit Protection | Red led light | ||
| Battery Low Voltage Alarm | 21±0.5V, Red led light | ||
| Battery Low Voltage Protection | 20±0.5V,Dealy 3s, Red led light | ||
| Battery Low Voltage Recovery | 24±0.5V | ||
| Over Power Protection |
1600-2000W±100W（5S）, More than 3000W Protection Immediately. LED Display Shows "OVPR |
||
| Over Temperature Protection | Shutdown @≤85℃ ±5℃,Red led | ||
| Operating Temperature and humidity | 0～＋40℃, humidity: 20~90% | ||
| Storage Temperature and Humidity | –20～＋60℃, humidity: 20~80% | ||
| USB Port 1 | USB with 5V/ 2.1A | ||
| Short Circuit Protection（Pin1 to Pin4） | Shutdown | ||
| Over Current Protection（Pin1 to Pin4） | 3.0A ±0.3A | ||
| Output Rated Voltage(DC) | 21～30Vdc | ||
| Output Max.Current(DC) | 100A(Pulse 200A) | ||
| BATTERY | |||
| Type: | Lithium-Ion Battery(NCM) | Ni-MH Battery | |
| Nominal Energy: | 2.52kwh | 1.248kwh | 2.496kwh |
| Nominal Capacity: | 100Ah | 52Ah | 104Ah |
| Nominal Voltage: | 24V | 24V | 24V |
| Dimension: | L460*W480*H89mm | L600*W480*H89mm | L790*W480*H89mm |
| Weight: | 25 kg | 32 kg | 51kg |
| Nominal Charge current: | 10A | 10A | 20A |
| Max.Charge current: | 50A | 25A | 50A |
| Nominal Disharge current: | 60A | 50A | 100A |
| Max.Disharge current: | 100A(Pulse 200A) | 100A(Pulse 200A) | 100A(Pulse 200A) |
| Battery BMS Protection | Short circuit, Over temperature, Over charge/discharge, Over current | ||
| Design Life: | 10 Years(80% DOD @25℃) | 10 Years(80% DOD @25℃) | |
| Warranty | 4 Years | 6 Years | |
Application:
Industrial standby power supply(Communication, electric power, data center)
UPS,Solar energy storage
